PREMIUM 1.2067 / 1.3505

AISI / SAE L3 / L1

102Cr6 / 100Cr6

PREMIUM 1.2067 / 1.3505

102Cr6 / 100Cr6
€co-Präz®
-flat-
PRS
-round-
PRS / BA
-round-
Logo_Abrams_Ausrufezeichen
HIGHEST PRECISION!

Standard values

(1.2067)
Chemical designation: 102Cr6 / 100Cr6
Working hardness: 60-64 HRC
Delivery condition: maximum 223 HB
Chemical composition:
C Si Mn P S Cr Mo Ni
0,95

1,1
0,15

0,35
0,2

0,4
0

0,025
0

0,025
1,35

1,6
0

0,1
0

0,4

Technical properties

An all-purpose medium alloyed cold work tool steel with high hardenability, but low depth of hardening, good wear resistance and toughness. This steel grade belongs to the group of AISI / SAE L1 (roller bearing and ball bearing steel).


Applications

Drills, threading tools, centre lathes, milling cutters, reamers, small die plates, pressure rollers, cold rollings, measuring tools, cold pilger rollings, cold pilger jaws, gauges, mandrels, woodworking tools, cold extrusion tools, flanging rollers, shear knives, roller bearings, ball bearings (medium to large size).

An all-purpose medium alloyed cold work tool steel with high hardenability, but low depth of hardening, good wear resistance and toughness. This steel grade belongs to the group of AISI / SAE L1 (roller bearing and ball bearing steel).

Drills, threading tools, centre lathes, milling cutters, reamers, small die plates, pressure rollers, cold rollings, measuring tools, cold pilger rollings, cold pilger jaws, gauges, mandrels, woodworking tools, cold extrusion tools, flanging rollers, shear knives, roller bearings, ball bearings (medium to large size).

(1.2067)
Chemical designation: 102Cr6 / 100Cr6
Working hardness: 60-64 HRC
Delivery condition: maximum 223 HB
C Si Mn P S Cr Mo Ni
0,95

1,1
0,15

0,35
0,2

0,4
0

0,025
0

0,025
1,35

1,6
0

0,1
0

0,4
