PREMIUM 1.2360 / 1.2360 mod.

AISI / SAE ~Chipper / ~Chipper mod.

X48CrMoV8-1-1/ X48CrMoV8-1

PREMIUM 1.2360 / 1.2360 mod.

X48CrMoV8-1-1/ X48CrMoV8-1
€co-Präz®
-flat-
PRS / BA 1.2360
-round-
PRS / BA 1.2360 mod.
-round-
Logo_Abrams_Ausrufezeichen
ORDER THE SMALLEST AMOUNT - WITHOUT A MINIMUM ORDER VALUE!

Standard values

Chemical designation: X48CrMoV8-1-1/ X48CrMoV8-1
Working hardness: 50-60 HRC
Delivery condition: maximum 250 HB
Chemical composition:
C Si Mn P S Cr Mo V
0,45

0,5
0,7

0,9
0,35

0,45
0

0,02
0

0,005
7,3

7,8
1,3

1,5
1,3

1,5

Technical properties

Very robust cold work steel which can be used for a wide range of applications. Has a good through-hardenability and high toughness (reduced occurence of hard carbides with about 8% chromium compared to 12% chromium in AISI / SAE D2, AISI / SAE D6, AISI / SAE D3 mod.). High cutting power, high wear resistance as well as excellent tempering resistance.


Applications

Blanking tools, stamping tools, embossing tools, forming dies, press dies, die inserts, extrusion dies, reinforcements, cold extrusion tools, tube tools, cutting tools, industrial knives, wood chipping knives, veneer knives.

Very robust cold work steel which can be used for a wide range of applications. Has a good through-hardenability and high toughness (reduced occurence of hard carbides with about 8% chromium compared to 12% chromium in AISI / SAE D2, AISI / SAE D6, AISI / SAE D3 mod.). High cutting power, high wear resistance as well as excellent tempering resistance.

Blanking tools, stamping tools, embossing tools, forming dies, press dies, die inserts, extrusion dies, reinforcements, cold extrusion tools, tube tools, cutting tools, industrial knives, wood chipping knives, veneer knives.

Chemical designation: X48CrMoV8-1-1/ X48CrMoV8-1
Working hardness: 50-60 HRC
Delivery condition: maximum 250 HB
C Si Mn P S Cr Mo V
0,45

0,5
0,7

0,9
0,35

0,45
0

0,02
0

0,005
7,3

7,8
1,3

1,5
1,3

1,5

70 STEEL GRADES IN 32.629 DIMENSIONS

EX WORKS FROM OSNABRÜCK

DELIVERY IN 3-5 WORKING DAYS (SUBJECT TO AVAILABILITY)

WITHOUT MINIMUM ORDER VALUE OR QUANTITY

FROM EUROPE'S LARGEST RANGE OF SEMI-FINISHED PRODUCTS

SPECIAL CUSTOM DIMENSIONS SAWN - MILLED - GROUND
